N50 Fanless Industrial PC, 6× COM — BOTO IPC122-2L6C10U-A2

LAN Portsi3-10110u/i5-10210u/i7-10510u/125U/125H/155H/185H: 1*intel i219LM+i226v (compatible with i226-LM, supports Vpro) supports WOL and PXE boot / N50/N95/N97/N100/N150: 2* Intel i210 Gigabit Ethernet ports, supporting WOL and PXE boot / i3-1125G4/i5-1135G7/i7-1165G7: 1*intel i219LM+i210AT (supporting Vpro) supports WOL and PXE boot

Memory1*D5-5600MHz，Supports up to 48GB

Dimensions195×127×62 mm

Temp RangeOperating temperature: -10℃~60℃

Get a Quote →

Prices, MOQ and lead time available on request — contact leo@botoipc.com.

Key Features

Truly fanless fin-stack heat sink — zero moving parts, silent and dust-resistant for 24/7 industrial operation.
i3-10110u/i5-10210u/i7-10510u/125U/125H/155H/185H: 1*intel i219LM+i226v (compatible with i226-LM, — Wake-on-LAN and PXE boot ready for networked gateways and machine vision.
The 6*DB9 — direct integration with PLC, CNC, sensors and SCADA (RS485/422 options where supported).
N50/N95/N97/N100/N150：1*D4-3200Mhz Supports up to 16GB / i3-8145u/i5-8257u/i5-8365u/i7-8569u：1*D4-2400MHz，Supports up to 32GB / i3-10110u/i5-10210u/i7-10510u/i3-1125G4/i5-1135G7/i7-1165G7：1*D4-3200MHz，Supports up to 32GB / 125U/125H/155H/185H：1*D5-5600MHz，Supports up to 48GB.
N50/N95/N97/N100/N150: 1*DP(1.4a), 1*HDMI 2.0b, supports synchronous and asynchronous dual display / i3-10110u/i5-10210u/i7-10510u/i3-1125G4/i5-1135G7/i7-1165G7: 1*DP, 1*HDMI support for synchronous and asynchronous dual display / 125U/125H/155H/185H: 1*DP, 1*HDMI (HDMI 2.1 supports 8K@60HZ) supports synchronous and asynchronous dual display — dual independent display support.
i3-8145u/i5-8257u/i5-8365u/i7-8569u/N50/N95/N97/N100/N150/i3-10110u/i5-10210u/i7-10510u：4*USB 3.2(10Gbps)+6*USB 2.0 / i3-1125G4/i5-1135G7/i7-1165G7：3*USB 3.2(10Gbps)+7*USB 2.0 / i3-6100u/i5-6200u/i7-6500u/i5-7200u/i7-7600u/125U/125H/155H/185H：2*USB 3.2(10Gbps)+8*USB 2.0 for high-speed peripherals.

Specifications

Processor (CPU)	Compatible with multiple Intel processors：N50/N95/N97/N100/N150/i3-8145u/i5-8257u/i5-8365u/i7-8569u/i3-10110u/i5-10210u/i7-10510u/i3-1125G4/i5-1135G7/i7-1165G7/125U/125H
System Memory	N50/N95/N97/N100/N150：1D4-3200Mhz Supports up to 16GB / i3-8145u/i5-8257u/i5-8365u/i7-8569u：1D4-2400MHz，Supports up to 32GB / i3-10110u/i5-10210u/i7-10510u/i3-1125G4/i5-1135G7/i7-1165G7：1D4-3200MHz，Supports up to 32GB / 125U/125H/155H/185H：1D5-5600MHz，Supports up to 48GB
Storage / Drive Bays	N50/N95/N97/N100/N150: 1M.2 M Key (Adaptive to PCIEx1 and SATA3.0 hard drives) / i3-8145u/i5-8257u/i5-8365u/i7-8569u：1M.2 / i3-10110u/i5-10210u/i7-10510u/i3-1125G4/i5-1135G7/i7-1165G7: 1M.2 Key-M 2280 (PCIEx4 and SATA3.0 hard drive, requires jumper setting for switching) / 125U/125H/155H/185H: 1M.2 Key-M 2280 (PCIEx4 and SATA3.0 hard drive adaptive)
Cooling	Fanless Ice Spike Cooling
Supported OS	Win7/Win10/Linux/Ubuntu
Ethernet (LAN)	i3-10110u/i5-10210u/i7-10510u/125U/125H/155H/185H: 1intel i219LM+i226v (compatible with i226-LM, supports Vpro) supports WOL and PXE boot / N50/N95/N97/N100/N150: 2 Intel i210 Gigabit Ethernet ports, supporting WOL and PXE boot / i3-1125G4/i5-1135G7/i7-1165G7: 1*intel i219LM+i210AT (supporting Vpro) supports WOL and PXE boot
Serial Ports (COM)	The 6*DB9 serial port is shipped with RS232 as the default, with COM1 supporting TTL signals, and COM2 and COM3 allowing RS485 signal settings through jumpers
USB Ports	i3-8145u/i5-8257u/i5-8365u/i7-8569u/N50/N95/N97/N100/N150/i3-10110u/i5-10210u/i7-10510u：4USB 3.2(10Gbps)+6USB 2.0 / i3-1125G4/i5-1135G7/i7-1165G7：3USB 3.2(10Gbps)+7USB 2.0 / i3-6100u/i5-6200u/i7-6500u/i5-7200u/i7-7600u/125U/125H/155H/185H：2USB 3.2(10Gbps)+8USB 2.0
Display Output	N50/N95/N97/N100/N150: 1DP(1.4a), 1HDMI 2.0b, supports synchronous and asynchronous dual display / i3-10110u/i5-10210u/i7-10510u/i3-1125G4/i5-1135G7/i7-1165G7: 1DP, 1HDMI support for synchronous and asynchronous dual display / 125U/125H/155H/185H: 1DP, 1HDMI (HDMI 2.1 supports 8K@60HZ) supports synchronous and asynchronous dual display
Expansion Slots	N50/N95/N97/N100/N150/i3-8145u/i5-8257u/i5-8365u/i7-8569u/i3-10110u/i5-10210u/i7-10510u/i3-1125G4/i5-1135G7/i7-1165G7/125U/125H：1个M.2 B Key，Supports 4G/5G modules. (M.2 E Key is optional, supporting WIFI6 and Bluetooth) / i3-10110u/i5-10210u/i7-10510u: 1M.2 A Key, supporting WiFi/Bluetooth module expansion, 1M.2 B Key, supporting 3G/4G module
Power Input	i3-6100u/i5-6200u/i7-6500u/i5-7200u/i7-7600u：1DC 12V 5525mm / N50/N95/N97/N100/N150/i3-1125G4/i5-1135G7/i7-1165G7/125U/125H：1DC 9~36V 5525mm / i3-10110u/i5-10210u/i7-10510u：1DC 12~24V 5525mm
Operating Temperature	Operating temperature: -10℃~60℃ / Storage temperature: -20℃~70℃
Dimensions (L×W×H)	19512762 mm

Applications

Factory Automation & SCADA — multi-port RS232/485 for PLC, CNC and robot controllers.
Edge Computing & IoT Gateway — fanless 24/7 deployment at the edge.
Digital Signage & Kiosk — compact size, silent operation, dual displays.
Network Security & NVR — reliable multi-LAN appliance platforms.
