IPC122-2L6C8U-A1 — Fanless Industrial PC

Fanless 2× Gigabit Ethernet · up to 64GB · -20~60°C wide temperature — compact 195×127×62 mm industrial box PC for 24/7 deployment.

OS compatible: pfSense · OPNsense · OpenWrt · RouterOS (x86) · Windows · Linux

LAN Portsi3-4005u/i5-4200u/i7-4500u/i3-5005u/i5-5200u/i7-5500u/i3-10110u/i5-10210u/i7-10510u：2*intel i211/i210AT Supports WOL and PXE boot / i3-6100i/i5-6200u/i7-6500/i3-7100u/i5-7200u/i7-7500u：1*intel i211/i210AT+1*intel i219V Supports WOL and PXE boot

Memory2*D4-2666Mhz Supports up to 64GB

Dimensions195×127×62 mm

Temp RangeOperating temperature: -10℃~60℃

Get a Quote →

Prices, MOQ and lead time available on request — contact leo@botoipc.com.

Key Features

Truly fanless fin-stack heat sink — zero moving parts, silent and dust-resistant for 24/7 industrial operation.
i3-4005u/i5-4200u/i7-4500u/i3-5005u/i5-5200u/i7-5500u/i3-10110u/i5-10210u/i7-10510u：2*intel i211/i210AT — Wake-on-LAN and PXE boot ready for networked gateways and machine vision.
Supports 6 RS232 — direct integration with PLC, CNC, sensors and SCADA (RS485/422 options where supported).
i3-4005u/i5-4200u/i7-4500u/i3-5005u/i5-5200u/i7-5500u：2*D3L-1600Mhz Supports up to 16GB / i3-6100i/i5-6200u/i7-6500/i3-7100u/i5-7200u/i7-7500u：2*D4-2133Mhz Supports up to 32GB / i3-10110u/i5-10210u/i7-10510u/J4125：2*D4-2666Mhz Supports up to 64GB.
1*HDMI 2.0 / 1*VGA — dual independent display support.
4*USB 3.0+4*USB 2.0 for high-speed peripherals.

Specifications

Processor (CPU)	Compatible with multiple Intel processors：i3-4005u/i5-4200u/i7-4500u/i3-5005u/i5-5200u/i7-5500u/i3-6100u/i5-6200u/i7-6500u/i3-7100u/i5-7200u/i7-7500u/i3-10110u/i5-10210u/i7-10510u/J4125
System Memory	i3-4005u/i5-4200u/i7-4500u/i3-5005u/i5-5200u/i7-5500u：2D3L-1600Mhz Supports up to 16GB / i3-6100i/i5-6200u/i7-6500/i3-7100u/i5-7200u/i7-7500u：2D4-2133Mhz Supports up to 32GB / i3-10110u/i5-10210u/i7-10510u/J4125：2*D4-2666Mhz Supports up to 64GB
Storage / Drive Bays	1MSATA 3.0 / 1SATA 3.0
Cooling	Fanless Ice Spike Cooling
Supported OS	Win7/Win10/Win11/Linux/Ubuntu
Ethernet (LAN)	i3-4005u/i5-4200u/i7-4500u/i3-5005u/i5-5200u/i7-5500u/i3-10110u/i5-10210u/i7-10510u：2intel i211/i210AT Supports WOL and PXE boot / i3-6100i/i5-6200u/i7-6500/i3-7100u/i5-7200u/i7-7500u：1intel i211/i210AT+1*intel i219V Supports WOL and PXE boot
Serial Ports (COM)	Supports 6 RS232 serial ports, with other COM1-2 ports supporting RS485/RS422
USB Ports	4USB 3.0+4USB 2.0
Display Output	1HDMI 2.0 / 1VGA
Expansion Slots	1*Minipcie Supports 4G module/WiFi module, Bluetooth function
Power Input	DC 12~24V 55*25mm
Operating Temperature	Operating temperature: -10℃~60℃ / Storage temperature: -20℃~70℃
Dimensions (L×W×H)	19512762 mm

Applications

PLC & Sensor Integration — serial ports for direct machine control.
Edge Computing & IoT Gateway — fanless 24/7 deployment at the edge.
Digital Signage & Kiosk — compact size, silent operation, dual displays.
Network Security & NVR — reliable multi-LAN appliance platforms.

Built-to-Order Options

Memory: capacity configured at RFQ (see specifications for max).
Storage: M.2 NVMe / SATA SSD / mSATA capacity per RFQ.
Serial: COM ports factory-configured to RS485 / RS422 / TTL on request.
Wireless: Mini-PCIe / M.2 4G/5G and Wi-Fi + Bluetooth options.
OS: Windows 10/11, Ubuntu, Debian, CentOS pre-install available.

Request a Quote — IPC122-2L6C8U-A1

Our engineering team replies within 1 business day with FOB Shenzhen pricing and lead time.

Tell us your CPU, memory, storage and interface requirements. Every unit is built-to-order from our Shenzhen factory.

✔ Direct factory pricing & OEM/ODM support

✔ Windows / Linux pre-install available

✔ Sample testing before bulk orders
