IPC122-3L6C8U-A1 — Fanless Industrial PC

Fanless 2× Gigabit Ethernet · 6× serial COM ports · up to 64GB · -20~60°C wide temperature — compact 195×127×62 mm industrial box PC for 24/7 deployment.

OS compatible: pfSense · OPNsense · OpenWrt · RouterOS (x86) · Windows · Linux

LAN Ports2*intel i211/i210AT+1*intel i226 supports WOL and PXE boot

Memory1*D5-4800Mhz Supports up to 64GB

Dimensions195×127×62 mm

Temp RangeOperating temperature: -10℃~60℃

Get a Quote →

Prices, MOQ and lead time available on request — contact leo@botoipc.com.

Key Features

Truly fanless fin-stack heat sink — zero moving parts, silent and dust-resistant for 24/7 industrial operation.
2*intel i211/i210AT+1*intel i226 — Wake-on-LAN and PXE boot ready for networked gateways and machine vision.
6*RS232 — direct integration with PLC, CNC, sensors and SCADA (RS485/422 options where supported).
1*D5-4800Mhz Supports up to 64GB.
2*HDMI 2.0 — dual independent display support.
2*USB 3.0+6*USB 2.0 for high-speed peripherals.

Specifications

Processor (CPU)	Compatible with multiple Intel processors：i3-1215u/i5-1235u/i7-1255u/i3-1315u/i5-1335u/i7-1355u
System Memory	1*D5-4800Mhz Supports up to 64GB
Storage / Drive Bays	1M.2 nvme/ngff / 1SATA 3.0
Cooling	Fanless Ice Spike Cooling
Supported OS	Win10/Win11/Linux/Ubuntu
Ethernet (LAN)	2intel i211/i210AT+1intel i226 supports WOL and PXE boot
Serial Ports (COM)	6*RS232 serial ports, with other COM1-2 ports supporting RS232/RS485/RS422
USB Ports	2USB 3.0+6USB 2.0
Display Output	2*HDMI 2.0
Expansion Slots	1M.2 B-key, Supporting WiFi/Bluetooth module expansion, Supporting 3G/4G/5G module / 1Minipcie Supports 4G module/WiFi module, Bluetooth function
Power Input	DC 9~36V 55*25mm
Operating Temperature	Operating temperature: -10℃~60℃ / Storage temperature: -20℃~70℃
Dimensions (L×W×H)	19512762 mm

Applications

Factory Automation & SCADA — multi-port RS232/485 for PLC, CNC and robot controllers.
Edge Computing & IoT Gateway — fanless 24/7 deployment at the edge.
Digital Signage & Kiosk — compact size, silent operation, dual displays.
Network Security & NVR — reliable multi-LAN appliance platforms.
